ERNiCrMo-10 is a nickel chromium molybdenum alloy wire designed for joining Alloy C22, 625, 825 or combinations of these alloys, or other Ni-Cr-Mo alloys to themselves or to stainless steels. Washington Alloy C22 is equivalent to AlloyC22 and is also used extensively for overlays and cladding of lower alloy steels. Washington Alloy C22weld deposits offer better overall resistance to weld metal corrosion than most other Ni-Cr-Mo alloys such as C276, C4 and 625. Washington Alloy C22 has outstanding resistance to pitting, crevice corrosion and stress-corrosion cracking. This alloy is used in chemical processing application involving ferric and cupric and inorganic, chlorine formic and acetic acids, acetic anhydride, sea water, and brine solutions.
ERNiCrMo-10 Specifications
| Grade | UNS |
| ERNiCrMo-10 | N06022 |
ERNiCrMo-10 Chemical composition
| Grade | % | Ni | C | Fe | Mn | Si | Cu | Co | W | Cr | Mo | V |
| ERNiCrMo-10 | Min | Bal. | 2 | 2.5 | 14.5 | 12.5 | ||||||
| Max | 0.015 | 6 | 0.5 | 0.08 | 0.5 | 2.5 | 3.5 | 16.5 | 14.5 | 0.35 |
ERNiCrMo-10 Mechanical properties:(Minimum value at 20℃)
| Tensile Strength
σb/MPa |
Yield Strength
σp0.2/MPa |
Elongation
σ5/% |
| 527 | 779 | 47 |
ERNiCrMo-10 Standards
| Welding Wire | Welding Strip |
| AWS A5.14 | AWS A5.14 |
